ARB Hydraulic Jack


  • Brand: ARB
  • Availability: In Stock
  • Part Number: 1060001


Hydraulic Lift: ARB engineered their Hydraulic Long Travel Recovery Jack to make vehicle recovery easy. The jack will lift up to half an inch with a single pump. Press the lowering lever, and the two-stage decent feature and safety stop will allow you to gently place your Jeep back on the ground. For additional safety, the Jack has a built-in internal blow-off valve, so it will not allow you to dangerously exceed the working load limit.

Adjustable Design: The body has 9 mounting locations for the adjustable hook. For a secure lifting platform, the Jack’s foot can be rotated 360° to match any terrain. The Jack’s built-in rubber bumper protects your Jeep from scuffs and scratches.

Heavy-Duty Construction: The body of the Jack is made from 6061 T6 aluminum and the shaft is corrosion resistant military grade nitride. These durable materials allow the Jack to have a maximum lift capacity of 4,409lbs.

Technical Specifications:

Shipping Dimensions: 35” x 8” x 6”

Shipping Weight: 28lbs

Base Diameter: 6.5”

Minimum Lifting Height: 6in

Maximum Lifting Height: 28” – 48”

Travel: 21” – 22”

Lifting Range: 6” – 48”

Maximum Capacity: 4,409lbs

Compressed Height: 35”

Extended Height: 56”

Weight: 23lbs

Lift Per Stroke: 0.5”
